Low profile acoustic cabinet fans
CAB ECOWATT Series

> Download images

Serial CAB-ECOWATT

CAB-200 ECOWATT 230V50/60HZ N8

  • CAB-ECOWATTbdp532
  • CAB-ECOWATTbdp547
  • CAB-ECOWATTbdp483

CAB-200 ECOWATT 230V50/60HZ N8

Low profile acoustic cabinet fans, manufactured from galvanised sheet steel and internally lined with 50mm thickness of fireproof acoustic insulation (M0), with sound-absorbent insulation at the inlet.
All models incorporate inlet and discharge circular duct connection flanges with integrated rubber air seal. Direct drive backward curved centrifugal fan.
Brushless EC motor, IP44, with thermal overload protection, suitable for single phase supply 230V +/- 15%- 50/60Hz.
Fan supply with external ON-OFF electrical isolation switch, and potentiometer to adjust the fan speed.
Also possible to control the fan speed with external potentiometer type REB-ECOWATT or analogue input signal 0-10V.
This cabinet fan has been designed for indoor use, with inlet air temperatures between -20ºC up to +40ºC and suitable for mounting in any orientation.

Technical data

Acoustic characteristics

Technical characteristics

Curves

Dimensions

ErP Information
