SILENT DESIGN
Bathroom extract fans
SILENT DESIGN Series
SILENT DESIGN Series
Show More
Show Less
Range of axial extractors with airflow rates of approx. 85 m3/h, for connection to 100 mm diameter circular ducting.
Motor mounted on silent-elastic-blocks which absorb the vibrations and allow offering very low noise level. All the fans are manufactured from injection moulded plastic, fitted with automatic shutter and single phase 230V-50Hz, class B low consumption motor equipped with thermal overload protection. All the fans are class II insulation, IP45 rated and suitable to operate with air temperature up to 40ºC.
Motor mounted on silent-elastic-blocks which absorb the vibrations and allow offering very low noise level. All the fans are manufactured from injection moulded plastic, fitted with automatic shutter and single phase 230V-50Hz, class B low consumption motor equipped with thermal overload protection. All the fans are class II insulation, IP45 rated and suitable to operate with air temperature up to 40ºC.
Attributes
Back draft shutter
To prevent air entry and limit heat leakage when the extractor is not operating. It opens due to the pressure of the air.
Silent-blocks
Motor mounted on “Silent-elastic-block” to prevent vibration and noise transmission.
SILENT-100 DESIGN
Quiet operation
In usual extract fans the vibrations are transmitted to the surrounding areas while in SILENT extractor fans the vibrations are absorbed by the Silent Blocks.
USUAL EXTRACTOR
Interchangeable bars colours
Interchangeable bars colours let the fan blend in with every setting. 4 colours to match the decor of the room: blue, red, green and yellow.
SILENT-100 CZ DESIGN 4C: Different colours available.
4C models incorporate 5 interchangeable bars colours (transparent, blue, green, red and yellow).
