CADB/T-N

Compact heat recovery unit with cross-flow heat exchanger in 9 sizes from 500 m3/h to 8.350 m3/h.
The casing is made from aluminium profile frame with double skinned 25 mm steel panels with mineral wool insulation.
It is designed to be as compact as possible for false ceiling applications.
The casings incorporate top, bottom and side access panels for maintenance.
The outside skin is from PVC coated steel and the inner skin is pre-galvanised steel.
The units are available in horizontal and vertical versions.

Applications
Public buildings, commercial offices, stores, schools and restaurants.

CADB/T-N D
Heat recovery units without additional incorporated heater.

Motors
IP44, Class F (Models 05, 08, 45 and 55).
IP20, Class F (Models 12, 18, 23 and 30).
IP55, Class F (Model 80).

Fans
All fans installed in CADB/T-N models, comply with the efficiency requirements of the ErP Directive.

Filters
- F7: Low pressure F7 filters for supply and extract air.
Possibility of mounting a second filter (accessory).

Additional information
Single phase (CADB-N) and three phase models (CADT-N).
Horizontal and vertical version.
Highest mounting flexibility given by the interchangeable side panels.
