Hot water coil
MBW Series

MBW

> Télécharger les images
  • Imprimer cette page
  • Télécharger la page catalogue en pdf

MBW

Features
Range of connection diameters, 100 to 500 mm.
Galvanised steel housing.
Heaters with copper pipes and aluminium fins.
Removable side for maintenance purposes.
Can be mounted horizontally or vertically.
Connections with watertight seals.
Connection must be made between the heater and the hot water circuit.
Maximum pressure: 10 bar.
Maximum temperature: 100ºC.
Shut-off valves must be installed on each water connection, so that the unit can be isolated if necessary (for cleaning filters, repairs, etc.) without the need to drain the entire circuit.
We recommend installing a filtration box with a filter (MFL-F + MFR) at the input to the unit, to capture water borne debris.
